BORA ULTRA WTO 45 DISC BRAKE
Campagnolo’s Bora Ultra WTO 45 has the perfect balance of speed, agility and stability, making it the best choice for all-round riders. The rim’s versatile design takes account of real-world riding conditions, not just those created in a wind tunnel, and the result is the most efficient drag-reducing rim shape available.

Now even lighter, thanks in part to its Hand Made Ultra-Light Carbon (H.U.L.C.) construction, the Bora Ultra WTO 45 has slimmer Aero Elliptical spokes and hidden nipples to help slice through the air. Campagnolo’s beautifully moulded carbon hub body is securely bonded to a light aluminium hub flange, and integrated radial spoke seats ensure perfect alignment. A uniquely stunning C-LUX finish and new, subtle Bora Ultra graphics ensure the new wheels have the show to match their go.

Campagnolo’s CULT ceramic bearings spin effortlessly within both the front aerodynamic carbon body and the rear aluminium shell of the disc hubs. The rear oversized 36 tooth ratchet system can be driven by N3W, XDR or HG freehub bodies.

The 2-Way Fit rims are ready for immediate tubeless use without rim tape, designed for tyre widths from 23mm, they’re aerodynamically optimised for 25mm tyres.

SPECIFICATIONS
SPOKES
Spokes: 24 Aero Elliptical, straight pull, double-butted
Spoke pattern G3
Nipples Aluminium Aero Mo-Mag, self-locking, internal
VERSIONS AND WEIGHTS
Campagnolo N3W FW body
HG FW body
XDR FW body
1.425 g
front 660 g
rear 765 g

COMPATIBILITY
Campagnolo sprocket set 11/12/13
Shimano sprocket set 10/11 - SRAM 10/11
SRAM 12 sprocket set

HUB
Hub type: Bora Ultra, carbon body
Rear hub type: Aluminium body, 36 tooth ratchet freehub
Hub width: 100-142mm
Axle type: 12mm aluminium thru axle
Bearings: CULT ceramic, cup and cone
Brake interface: AFS disc
Freehub compatibility: N3W, XDR, HG

RIM
ASTM classification: 1
Material: H.U.L.C UD high-strength carbon fibre
Finish: C-LUX
Tyre interface: 2-Way Fit
Tyre compatibility: Tubeless, tubeless-ready, clincher
Recommended tyre size: 700c, from 23mm
Rim height: 45mm
Internal width: 19mm
External width: 26.1mm
Decals: Water transfer DCS (Dark, copper shaded)

TYRES
Tubeless
Tubeless-ready
Clincher

ASSEMBLY
The Bora™ Ultra WTO™ 45 Disc Brake wheel is entirely hand-assembled by a specialised Campagnolo® technician and is 100% checked by electronic instrumentation. This procedure ensures that every single Campagnolo® wheel offers maximum performance and reliability

COMES WITH
Aero Mo-Mag nipple maintenance kit
Tubeless valves
AFS lockrings
Campagnolo wheel bags
Campagnolo accessories bag
Tyre levers
Campagnolo N3W Z11 adapter (on Campy freehub version).

Available versions: Campagnolo N3W™, Shimano HG, Sram XDR™ FW hub
